Impex Pulverizer

Impex Pulverizer

Varahi Industries’ Impex Pulverizer is a high-performance milling machine for fine powder production across chemicals, agriculture, minerals, metals and specialty materials.

Pulverization occurs by continuous impact of rotating hammers on grinding liners with a controlled air stream conveying ground material to the outlet. Oversize is returned via the whizzer classifier to ensure uniform particle size.

Miracle Mill / Hammer Mill is the high-production variant using a perforated liner for classification—ideal for medium-fineness requirements.

Enquire Now

Working Principle

Technical Specifications

Model Motor (HP) RPM Fineness (Mesh) Output (Kg/Hr)
VIP-12 7.5 2800–3500 100–300 50–60
VIP-16 10 2800–3500 100–300 80–100
VIP-20 10–15 2200 75–300 80–300
VIP-25 20–30 2000 75–300 150–450
VIP-32 (WC) 50–60 1800 75–300 400–900
VIP-42 80–100 1800 75–300 600–1500

All data are nominal and may vary with material properties and operating conditions.

Enquire Now

Major Components

  • Main Body: Cast-iron chamber with replaceable liners; integrated metal trap.
  • Feeder: Automatic variable-speed star feeder for controlled feed.
  • Rotor: Thick plate rotor with hinged hammers; heavy-duty dust-proof bearings.
  • Whizzer: Conical classifier with adjustable blades (100–300 mesh).
  • Blower: Heavy-duty bolted blades for long life; easy replacement.
  • Cyclone Collector: Efficient powder–air separation for clean operation.

Key Benefits

  • High grinding efficiency with uniform particle size.
  • Handles hard, brittle, and fibrous materials.
  • Adjustable fineness and output capacity.
  • Dust-free operation with cyclone and dust collector.
  • Low maintenance; easy access to replaceable parts.
  • Suitable for lab-scale and industrial production.

Applications

Chemicals

Pigments, intermediates, dyes, organics

Agriculture

Spices, guar gum, flour, turmeric, herbal powders, prawn feed

Minerals

Bauxite, calcite, coal, limestone, soapstone, china clay, dolomite, gypsum, marble, POP

Metals

CI powder, ferro alloys, zinc & brass dross

Others

Pesticides, insecticides, precipitated silica, carbon black

After-Sales Support
